Vertical Carbon Filter Sour Service 72? ID x 20?-0? S/S x 256 PSI

Description

VERTICAL CARBON FILTER Built in 2009 as Rich Amine Carbon Filter Sour Service PS Filter Model: 72-240-#F-258 72? ID x 20?-0? S/S 256 PSI @ 212° F Inlet & OutLet: 3? 150# RF Manways: 2 x 24? CA: 0.125? MDMT: -50° F Element Type: Dumped Carbon Design Capacity: Insulated: Yes Heat Traced: Bottom 1/3 CRN#: U-8910.2 “U” Stamp: Yes National Board #: Yes, Overall Height: 132?, Shipping Weight: 22,000 Lbs.

Prize: $930,000.00
